| Beheerfuncties |
|---|
| Switch type | Managed |
| Switch-laag | L2+ |
| Multicast-ondersteuning | Ja |
| Web-gebaseerd management | Ja |
| MIB-ondersteuning | RFC2925, RFC2618, RFC2620, RFC2021, RFC2819, RFC2674, RFC1493, RFC1643, RFC2233, RFC1213 |
| System event log | Ja |
| Traffic-classificatie | Ja |
| ARP-inspectie | Ja |
| Locatie-instellingen (CLI) configureren | Ja |
| Cloud-beheerd | Ja |
| Poorten & interfaces |
|---|
| Aantal basis-switching RJ-45 Ethernet-poorten | 8 |
| Console port | RJ-45/micro-USB |
| Type basis-switching RJ-45 Ethernet-poorten | 2.5G Ethernet (100/1000/2500) |
| Aantal moduleslots SPF+ | 2 |
| Aantal 2.5G Ethernet (koper)poorten | 8 |
| Data-uitwisseling |
|---|
| MAC-adrestabel | 16000 entries |
| Switchingcapaciteit | 80 Gbit/s |
| Aantal VLANs | 4000 |
| Aantal statische routes | 48 |
| Aantal IP-interfaces | 16 |
| Static route | Ja |
| Beveiliging |
|---|
| MAC adres filtering | Ja |
| Statische poort beveiliging | Ja |
| Access Control List (ACL) | Ja |
| SSH/SSL support | Ja |
| Bescherming lus | Ja |
| BPDU filtering / bescherming | Ja |
| Authenticatie | MAC-gebaseerde authenticatie, Poortgebaseerde authenticatie |
| IP-MAC-Port binding | Ja |
| Algoritmen wachtrijplanning | SP, WRR+SP, Weighted Round Robin (WRR) |
| DHCP features | DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping |
| Netwerk |
|---|
| Port mirroring | Ja |
| Verbindingsaggregatie | Ja |
| Broadcast stormbeheer | Ja |
| IP routing | Ja |
| IGMP snooping | Ja |
| 10G support | Ja |
| VLAN=ondersteuning | Ja |
| Head-of-line (HOL) blocking | Ja |
| Spanning tree protocol | Ja |
| Rate limiting | Ja |
| Virtuele LAN-functies | MAC address-based VLAN, Port-based VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN |
| Design |
|---|
| Rack-montage | Ja |
| Eisen aan de omgeving |
|---|
| Warmtedissipatie | 51,18 BTU/h |
| Prestatie |
|---|
| Packet buffergeheugen | 12 MB |
| Koeling |
|---|
| Aantal ventilatoren | 2 |
| Beveiliging |
|---|
| Wachtwoordbeveiliging | Ja |
| Verpakking |
|---|
| Type verpakking | Doos |
| Power voorraad |
|---|
| Vermogenstoevoer inclusief | Ja |
| Data-uitwisseling |
|---|
| Verzending snelheid | 59,52 Mpps |
| Technische details |
|---|
| Authenticatie type | AAA, TACACS+ |
| Energie |
|---|
| Netstekker | AC-in-aansluiting |
| Protocollen |
|---|
| GARP VLAN Registratieprotocol (GVRP) | Ja |
| Design |
|---|
| Fanloos | Ja |
| Multicast features |
|---|
| Multicast Listener Discovery (MLD) snooping | Ja |
| Kenmerken |
|---|
| Code geharmoniseerd systeem (HS) | 85176990 |
